Before you flash: Flashing firmware will erase all data on your device. Back up contacts, photos, and apps before proceeding. FlashGuideHub is not responsible for any damage caused by following this guide.
About the Motorola Moto G4
The Motorola Moto G4 (codename: athene) is a mid-range Android smartphone released in May 2016, powered by the Qualcomm Snapdragon 617 (MSM8952) chipset. Motorola distributed it across five XT hardware variants, each split further into subsidy-specific builds for different carriers and regions.
Each subsidy build carries a unique radio (modem) firmware — using the wrong build's package is a permanent error. The Prerequisites and Firmware Package sections below explain how to identify your exact build and select the correct package before you begin.
Which Flash Mode Should You Use?
Motorola Flashfile XML (mfastboot)
The standard method for the Moto G4. Reads flashfile.xml to write every partition — bootloader, radio, system — in one pass via mfastboot. Requires a prior bootloader unlock. Erases all user data.
Motorola Rescue and Smart Assistant
Motorola's official PC-based rescue tool can re-flash the device in certain scenarios and may not require a manually unlocked bootloader. Download from Motorola's support site, connect the phone via USB, and follow the on-screen instructions. Limited to Motorola-approved firmware versions and may not cover every subsidy build.
EDL / QFIL (Emergency)
The Snapdragon 617's Emergency Download mode is accessible via test points when the device is fully unresponsive. Requires Qualcomm programmer files not publicly distributed by Motorola. Not a standard user-accessible path — used only by service centres with proprietary tools. If mfastboot and Rescue and Smart Assistant both fail, contact Motorola support directly.
What You Need Before Flashing
Required to run mfastboot commands and the flashfile script. Install Android SDK Platform Tools plus a Motorola-flavoured mfastboot binary — some CFC XML packages use flags stock fastboot doesn't support. Motorola USB drivers are required on Windows for the device to be recognised in Fastboot mode.
Flashfile XML flashing is only possible with a previously unlocked bootloader. Request your device-specific unlock code at motorola.com/unlock-bootloader using your IMEI and Android ID — note the Amazon Prime Exclusive XT1625 (AMZ) is not eligible while under the Amazon subsidy. The unlock wipes the device once — complete this before downloading firmware.
Download the CFC XML / factory image package that matches both your exact XT model number and subsidy tag (e.g. RETUS, AMZ, CCAWS, TESCOEU, MOVSTLA, LATAM). Confirm in Settings → About Phone → Model Number and cross-check with fastboot getvar all. The wrong subsidy package carries a different radio firmware and will corrupt cellular connectivity if flashed.
A data-capable USB cable is essential — charge-only cables do not support Fastboot communication. Use the original Motorola cable or a known-good data cable. Avoid USB hubs; connect directly to a port on your PC.
The flashfile script writes multiple partitions over several minutes. Unlike the Moto G4 Play, the Moto G4's 3000mAh battery is non-removable — a power-off during radio or bootloader partition writes can cause a hard brick with no way to swap the battery. Charge to at least 50% before starting, and keep the USB cable connected throughout.
Both the bootloader unlock step and the flashfile script wipe all user data. Back up photos to Google Photos, contacts to Google Contacts, and app data or documents to a PC or cloud service before beginning.
How to Flash the Motorola Moto G4 — Quick Overview
7-step quick reference for the Motorola Moto G4. Need visuals or troubleshooting help? The full Motorola flashfile.bat / CFC XML Script guide covers everything in detail.
-
Identify your exact XT model and subsidy/branch
-
Request your bootloader unlock code and back up all data
-
Download the CFC XML / factory image package matching your build
-
Install Motorola USB drivers and mfastboot
-
Boot into Fastboot mode and run the flashfile script
-
Wait for completion and confirm IMEI/network on first boot
-
Re-lock the bootloader if you want official OTA updates (optional)
Finding the Firmware Package for MSM8952
The Moto G4 firmware is distributed as a factory image / CFC XML package containing separate .img files for each partition plus a flashfile.xml or flashfile.bat script that mfastboot reads to flash partitions in the correct order. After extracting the package, locate:
flashfile.xml
This file is inside the CFC XML / factory image archive. After extracting, look for flashfile.xml or flashfile.bat at the top level of the extracted folder, alongside individual .img files for each partition. Do not run the script from inside a compressed archive — fully extract to a folder on your PC before executing.
The Moto G4 (codename: athene) has five XT hardware variants, each split further into subsidy/carrier-specific builds (e.g. RETUS, AMZ, CCAWS, TESCOEU, MOVSTLA, LATAM) with their own radio (modem) firmware and CID: XT1621 (base ATHENE CID50, plus MSTLA, LATAM, and MOVSTLA subsidy builds), XT1622 (base ATHENE CID50, plus TESCOEU for Tesco Mobile Europe), XT1624 (base ATHENE, with an early and a later Nougat build), XT1625 (RETUS for US retail, AMZ for the Amazon Prime Exclusive unit, CCAWS for Canadian carrier units), and XT1626 (base ATHENE). Always match both the XT number and the subsidy tag in the filename — two builds can share an XT number and Android version yet still carry different, incompatible radio images.
Before flashing, run fastboot getvar all to read the device's current CID — this confirms which subsidy package is actually compatible, since outward branding does not always match the provisioned CID. A CID mismatch is the most common cause of a "Preflash validation failed" bootloader rejection (see Common Errors below).
Packages may ship as flashfile.bat + flashfile.xml, or as a CFC.xml-based archive — both work the same way once extracted and run through mfastboot.
Note: The Moto G4 Plus (XT1640/XT1642/XT1643, codename: griffin) is a different device with a fingerprint sensor and different partition layout. Its factory images are incompatible with the plain Moto G4 (athene). Never flash Moto G4 Plus images on a Moto G4 or vice versa.
Motorola Moto G4 Firmware Versions
Known stock firmware releases for the Motorola Moto G4. Always verify the version matches your device's exact XT model and subsidy before flashing.
| Version | Region | Android Version | Size | MD5 | Download |
|---|---|---|---|---|---|
MPJ24.139-23.4 / CID50 |
XT1621 — ATHENE (CID50) | Android 6.0.1 | 1.05 GB | — | ⬇️ Download |
NPJS25.93-14-10 / MSTLA |
XT1621 — MSTLA | Android 7.0 | 1.06 GB | — | ⬇️ Download |
NPJS25.93-14-15 / subsidy-LATAM |
XT1621 — LATAM | Android 7.0 | 1.07 GB | — | ⬇️ Download |
MPJ24.139-23.4 / subsidy-MOVSTLA |
XT1621 — MOVSTLA | Android 6.0.1 | 1.06 GB | — | ⬇️ Download |
MPJ24.139-48 / CID50 |
XT1625 — RETUS | Android 6.0.1 | 1.05 GB | — | ⬇️ Download |
NPJ25.93-14.7 / CID50 |
XT1625 — AMZ | Android 7.0 | 1.3 GB | — | ⬇️ Download |
NPJS25.93-14.7-5 / subsidy-CCAWS |
XT1625 — CCAWS | Android 7.0 | 1.06 GB | — | ⬇️ Download |
MPJ24.139-23.4 / CID50 |
XT1622 — ATHENE (CID50) | Android 6.0.1 | 1.06 GB | — | ⬇️ Download |
NPJS25.93-14-18 / subsidy-TESCOEU |
XT1622 — TESCOEU | Android 7.0 | 1.07 GB | — | ⬇️ Download |
NPJ25.93-11 / CID50 |
XT1624 — ATHENE (early Nougat) | Android 7.0 | 1.05 GB | — | ⬇️ Download |
NPJS25.93-14-18 / CID50 |
XT1624 — ATHENE (later Nougat) | Android 7.0 | 1.07 GB | — | ⬇️ Download |
MPJ24.139-23.1 / cid50 |
XT1626 — ATHENE | Android 6.0.1 | 1.10 GB | — | ⬇️ Download |
More builds and newer regional variants may be added over time. View the source listing on AndroidFirmwareFile.com →
Motorola Moto G4 — Important Notes
Motorola released official Android 7.0 Nougat factory images for several Moto G4 subsidy builds — including MSTLA and LATAM XT1621 units, TESCOEU XT1622 units, both XT1624 builds, and AMZ/CCAWS XT1625 units — while some CID50 base builds remained on 6.0.1 Marshmallow longer. Check the firmware table above for a Nougat-labelled build matching your exact XT number and subsidy before attempting an upgrade flash.
Unlike the Moto G4 Play's removable battery, the Moto G4's 3000mAh battery is sealed in. There is no way to pull the battery mid-flash if it drains, so charge to at least 50% and keep the USB cable connected throughout — a power interruption during the bootloader or radio partition writes is the scenario most likely to require Motorola Rescue and Smart Assistant or a service center to recover.
Common Errors on the Motorola Moto G4
"waiting for device" — mfastboot does not detect the phone
mfastboot cannot see the device. On Windows, check Device Manager for "Android Bootloader Interface" while the phone is in Fastboot mode — if it shows as unknown, reinstall the Motorola USB drivers. Use a data-capable USB cable and a USB 2.0 port rather than USB 3.0. Confirm the phone is actually showing the Fastboot logo, not a normal boot screen.
FAILED (remote: 'Bootloader is not unlocked')
The bootloader must be unlocked before any flashfile.xml flash. Complete the unlock process at motorola.com/unlock-bootloader with your IMEI and Android ID, then in Fastboot mode run fastboot oem unlock UNLOCK_CODE. This wipes the device and reboots it. Re-enter Fastboot mode and run the flashfile script again afterward. Note this option is not available on the Amazon Prime Exclusive XT1625 (AMZ) build.
flashfile.bat fails instantly / "Image not found" error
The flashfile script must be executed from within the extracted CFC XML / factory image folder — it references .img files and flashfile.xml by relative path. Do not double-click flashfile.bat from Windows Explorer; instead, open Command Prompt, navigate (cd) to the extracted folder, and run flashfile.bat from there. Also verify the archive was fully downloaded — a truncated ZIP produces an incomplete extraction with missing .img files.
FAILED (remote: 'image is not for this device')
The package you downloaded does not match this unit's XT number and subsidy. The bootloader checks the device/CID identifier embedded in the CFC XML package against the phone's provisioned CID and rejects mismatches. Confirm your XT number in Settings → About Phone, run fastboot getvar all to read the current CID, and download the package built for that exact combination from the firmware table below.
Device stuck on Motorola logo after flashing
An interrupted flash leaves one or more partitions inconsistent. Re-enter Fastboot mode (hold Volume Down + Power for 8–10 seconds) and re-run the flashfile script from scratch using the same package. If Fastboot mode is no longer reachable, Motorola Rescue and Smart Assistant can recover some units that are otherwise unresponsive to mfastboot commands.
(bootloader) Preflash validation failed
The bootloader rejected one or more partition images before writing, usually because the package's signed CID doesn't match the device's provisioned CID, or its security version is older than what's already flashed (anti-rollback). Run fastboot getvar all to confirm the device's current CID and only flash a package built for that exact CID/subsidy — this is a protective check, not damage, and should never be forced through.
IMEI reads 0/unknown or "No Service" after flashing
Almost always caused by flashing a package for the wrong subsidy build within the same XT number — each subsidy carries its own radio/modem image. Re-flash the package that exactly matches your XT number and subsidy tag from the firmware table below; the flashfile process does not normally touch the modemst1/modemst2 (EFS) partitions, so a correctly matched re-flash usually restores network function.
For the full Fastboot error database: Fastboot Error Directory →
Frequently Asked Questions — Motorola Moto G4
Go to Settings → About Phone → Model Number for the XT number. The subsidy or carrier tag is not shown on-screen — it is tied to the CID/branch your unit shipped with (e.g. RETUS for US retail XT1625, AMZ for the Amazon Prime Exclusive XT1625, CCAWS for XT1625 units sold through Canadian carriers, TESCOEU for XT1622 units sold via Tesco Mobile in Europe, MOVSTLA/LATAM for Latin American XT1621 units). Run fastboot getvar all in Fastboot mode to read the device's actual CID and cross-check it against the firmware table before flashing.
Motorola's official unlock tool at motorola.com/unlock-bootloader covers most Moto G4 units, but the Amazon Prime Exclusive XT1625 (AMZ) ships locked as part of the Amazon subsidy program and Motorola does not issue unlock codes for it while that subsidy applies. Carrier-tagged builds such as CCAWS or TESCOEU are typically retail-unlockable, but always confirm eligibility through the portal using your device's IMEI before assuming it is possible.
Motorola released official Android 7.0 Nougat factory images for several Moto G4 subsidy builds, including MSTLA and LATAM XT1621 units, TESCOEU XT1622 units, AMZ and CCAWS XT1625 units, and XT1624. Not every subsidy build received a Nougat image at the same time, and some CID50 base builds remained on 6.0.1 Marshmallow for longer. Check the firmware table below for a Nougat-labelled build matching your exact XT number and subsidy before attempting an upgrade flash.
The Snapdragon 617 (MSM8952) supports Qualcomm Emergency Download (EDL) mode at the hardware level, but Motorola does not publicly distribute the Qualcomm programmer (.elf/.mbn) files required for QFIL to talk to the device. EDL recovery on Moto G4 units is limited to Motorola-authorized service centers with access to those files. Motorola Flashfile XML (mfastboot) with the correct CFC XML package is the only publicly supported method for end users.
This is almost always a subsidy/CID mismatch — for example flashing a plain CID50 package onto an AMZ or CCAWS unit. Each subsidy build carries its own radio/modem image tied to that CID. Re-flash using the package that matches both your exact XT number and subsidy tag from the firmware table below; a correctly matched re-flash typically restores IMEI and signal since the flashfile process does not normally touch the modemst1/modemst2 (EFS) partitions.
